CSL DD (8 Nm, Refurbished)

• Direct-Drive system delivers instant, detailed force feedback

• Boost Kit 180 included

• Linear, consistent performance (8 Nm peak torque)

• Patented, exclusive FluxBarrier technology optimises motor efficiency and smoothness

• Full Fanatec SDK support ensures game compatibility out of the box for all major racing games

• Standard Tuning Menu allows beginners to get started quickly without having to worry about settings

• Advanced Tuning Menu allows enthusiasts to fine-tune the force feedback characteristics to suit their driving preferences

• High-resolution (contactless) Hall-position-sensor, same as Podium Series

• Steering axis made from carbon fibre-enhanced composite

• Fanless: wheel base housing is made from aluminium (passive heat sink, core structural component) with composite end caps

• Rotation: 2520 degrees (electronically limited, adjustable)

• Slip ring system (life-tested for thousands of hours) provides cable-free delivery of power and data to steering wheels

• Automotive-grade quick release, exchangeable

• T-nut rail system on sides and bottom for easily adjustable hard-mounting

• Optional table clamp (sold separately), supports 5 to 60 mm table thickness

• Ports:

  • Power supply

  • USB-C to PC / console

  • Fanatec DataPort-C

  • Shifter 1

  • Shifter 2 (Sequential only)

  • Pedal

  • Handbrake

• Front-mounted threaded inserts for Fanatec accessories (e.g. ClubSport Static Shifter Paddles, available separately). Not intended for front-mounting the wheel base to a sim racing chassis/cockpit.

The CSL DD is compatible with:

• Fanatec Podium Steering Wheels

• Fanatec ClubSport Steering Wheels

• Fanatec CSL Steering Wheels

• All Fanatec Pedals (adapter cables might be required on pedals without RJ12 connection)

• Fanatec ClubSport Shifters (including ClubSport Static Shifter Paddles)

• Fanatec ClubSport Handbrake V1 and V1.5

• Fanatec RennSport Cockpits

• ClubSport Table Clamp V2

• CSL DD Table Clamp

• Boost Kit 180

• Podium Mounting Brackets (the CSL DD includes M6 T-nuts for side-mounting; the Podium Mounting Brackets require the use of M6 bolts and washers)

• PC: This wheel base is compatible with PC when combined with a Fanatec Steering Wheel. Check the individual Steering Wheel product pages for Wheel Base compatibility.

• XBOX®: This wheel base becomes compatible with XBOX One® and XBOX Series X|S when used with any Fanatec XBOX-licensed steering wheel.

• PlayStation®: This product is not compatible with any PlayStation® console and cannot be upgraded to achieve compatibility.

• CSL DD wheel base

• QR1 Base-Side (Type-C) preinstalled

• Boost Kit 180 power supply (regional)

• 4x T-nuts for rail mount system

• USB cable (Type-C to Type-A)
